The R600L Series 10W LED is an economical and affordable trac fixture, with a simple and timeless aesthetic. It approximates the light output and distribution of 50W MR16 halogen lamps, utilizing about 20% of the energy and having a rated life of 50,000 hours.

Features

• Finish: Black, White
• Color Temperature: 2700K, 3000K, 3500K, 4000K
• CRI: 90
• Beam Spread: Narrow Flood, Flood, Universal Beam (includes narrow flood and flood lenses)
• It is compatible with Juno Trac-Lites and Trac-Master trac and system components
• It approximates the light output and distribution of 50W MR16 halogen lamps
• Average Life: 50,000 hours
• Integrated driver
• Provides quiet operation with or without dimming
• Dimmable using high quality dimmers approved by Juno – see R600L-DIM
• Bayonet mount lensholder facilitates lens changes in the field
• On/off switch included
• “Pull-up” contact to up position for two-circuit application
• Aiming: 350 horizontal coverage
• 90 vertical aiming capability
• Equivalent to 50W MR16 halogen
• Compatible with either Juno trac systems

Dimensions

• Diameter: 3-1/64″
• Height: 6-5/16″

Lamping

• 1 x 10W LED (Included)

Documents

• Spec Sheet
