This smart fan eclipses conventional ceiling fans in more ways than one. Eclipse integrates functionality, innovation, advanced technology and a stylish aesthetic that is visually compelling. Offered in three architectural finish combinations.

Features

• Finish/Blades:
  • Brushed Nickelwith Matte Black Blades
  • Soft Brass with Matte Black Blades
  • Soft Brass with Matte White Blades
• Blade Pitch: 13.5
• 5 blades
• Blade Material: Plywood
• Primary Material: Steel
• Power: 56W
• Voltage: 120V
• 6 fan speeds through both Summer and Winter Modes
• Silent DC motor
• Bluetooth remote control included
• Luminaire cover not available
• Compatible with WAC Smart Fans app

Airflow/Energy Efficiency

• Airflow: 5106 cubic ft per minute on high
• Power: 36 watts on high
• Airflow Efficiency: 133 cubic ft per minute per watt
• Revolutions Per Minute: 152 RPMs on high

Dimensions

• Blade Sweep: 54″
• Height: 14.6″
• Wire: 80″
• Canopy: 6.3″ Dia.
• Downrod: 4.5″
• Motor Type: 120 x 12 sensorless DC motor
• Hanging Weight: 14 lbs

Lamping

• 19.5W Integrated LED (Included)
• Color Temperature: 3000K
• Lumens: 1600
• CRI: 90
• LED Lifespan: 50,000 hrs

Documents

• Spec Sheet
• Instruction Sheet
