ATLANTIS from WAC LIMITED offers a Damp rated, high-value fan with three speed options and can be reversed from the housing to pull hot air up during winter months. Enhance your interiors with the gently-curved shape of this elegant fan.

Features

• Finish/Blades:
  • Brushed Nickel with Titanium Silver Blades
  • Matte Black with Matte Black Blades
  • Matte White with Matte White Blades
• Construction: Steel and Plywood Blades
• Blade Pitch: 13
• Three blades
• 3 Speed Reversing
• Voltage: 120V
• Pull chain operation

Airflow/Energy Efficiency

• Airflow: 4116 cubic ft per minute on high
• Power: 63 watts on high
• Airflow Efficiency: 75 cubic ft per minute per watt
• Revolutions Per Minute: 186 RPMs on high

Dimensions

• Blade Sweep: 52″
• Height: 12.2″
• Leadwire: 8″
• Ceiling to Blade Height: 7.9″
• Motor Type: 153 x 16 AC Motor

Lamping

• 19.5W LED (Included)
• Color Temperature: 3000K
• Lumens: 1600
• Delivered Lumens: 708
• CRI: 90
• Dimmable – 0-10v dimmer
• Rated Life: 50,000 Hours
