Features

• Finish: Black/Black, Black/Chrome, Black/Gold, Black/Haze, Black/White, White/Black, White/Chrome, White/Gold, White/Haze, White/White
• Power: 15W
• Input: 48 VDC
• Color Temperature: 2700K, 3000K, 3500K, 4000K
• Delivered Lumens: 1165-1325
• CRI: 90
• ELV Dimming: 100-0.1%
• 0-10V Dimming: 100-0.1%
• TRIAC Dimming: 100-0.1%
• Beam: 38
• Low glare trim with 25 shielding angle
• Rated Life: 50000 Hours
• Construction: Die-cast Aluminum with injection molded low glare trim
• To enable access to VENTRIX element releasing tabs, maintain at least 3 of free channel space
• Driver concealed within the fixture
• May be installed side by side or at L, X, T or end of run locations of VENTRIX channel
• Stealth Cube may be installed in surface, suspended or recessed VENTRIX system
• Can be mounted on ceiling or wall vertically or horizontally

Dimensions

• Length: 7.25″
• Width: 3.75″
• Height: 4.63″

Documents

• Spec Sheet
• Instruction Sheet
